Overview

The Transactions tab is designed for crypto-currency exchange. The list includes the transactions received by the White label for further exchange. The received transactions are presented in the exchange process as follows:

  1. A Client creates a request for cryptocurrency exchange using a White label service.

  2. The request is demonstrated in the Requests tab. See Requests for details.

  3. The Client deposits the exchanged amount to the account/address provided by the White label.

  4. Once the sum is successfully transferred to the account/address, the transaction is demonstrated in the Transactions tab.

  5. The White label administrator monitors the transactions received, identifies the Client, and confirms the request.

  6. Once the request is confirmed, an order is created and demonstrated in the Orders tab. The target currency is transferred to the Client’s account/address according to the corresponding order details. See Ordersfor details.

Opening the item

Follow the steps below to see the list of transactions:

  1. Navigate to the Admin Panel

  2. Click Exchange on the left sidebar

  3. Go to the Transactions menu item to open the List

Follow the steps below to browse transaction details:

  1. Navigate to the Admin Panel

  2. Click Exchange on the left sidebar

  3. Go to the Transactions menu item

  4. Click Show in the Action column to open the transaction details

Component parameters

Transaction Id – the column demonstrates internal identification numbers of the transactions received;

Request - the column shows the request that is related to the deposit transaction;

From address – the wallet number the transfer is sent from;

Currency – the currency of the received transaction;

Amount – the sum received;

Created at – date and time of transaction creation;

Action – click Show to browse the transaction details.

Configuring the component

The transaction details panel allows the user to browse the incoming transfer parameters.

Id – the field includes the parameters from the main list and the following:

Request – the unique request identification number;

Transaction Id - the unique identification number of the transaction received;

Block Id – the transaction block identification number – all transactions are grouped in blocks when received for better navigation and security;

Currency – the currency code of the transaction;

Amount – the transaction sum in the corresponding currency;

From address – the wallet address the transfer is received from;

To address – the wallet address the transfer is deposited to;

Confirmations – the number of blocks/transactions present chronologically after the current transaction block; confirmations improve transaction security.

Created at – date and time of transaction creation;

Received at – date and time when the transaction was received by the White label.
